E6581158
F-84
6
6.22.2 Using the RS232C/RS485
Q Setting the communication functions
Setting commands and frequencies by communications has priority over sending commands from the
operation panel or the terminal board. Command/frequency setting by communications can therefore be
enabled, irrespective of the setting in the command mode (EOQF) or the frequency setting mode (HOQF).
When inverters are connected to each others, however, in order for slave inverters to recognize frequency
signals from the master inverter as frequency commands, the frequency setting mode selection 1 parameter
(HOQF) provided for each slave inverter needs to be set to 4 (serial communications). Refer to the
COMMUNICATIONS EQUIPMENT USER'S MANUAL for details.
However, when the input terminal function selection parameter is set to 48: SC/LC (Serial/Local selection),
the inverter can be operated with the settings of the command mode (EOQF) or the frequency setting mode
(HOQF) by external input.
Q Transmission specifications
Item Specifications
Transmission scheme Half-duplex
Connection scheme Centralized control
Synchronization scheme Asynchronous
Transmission rate Default: 9600 baud (parameter setting)
Option: Either 1200, 2400, 4800, 9600, or 19200baud
Character transmission ASCII code: JIS X 0201 8, 8-bit (fixed)
Binary code: Binary, 8-bit (fixed)
Stop bit length Inverter receiving: 1 bit, Inverter sending: 2 bits
Error detection Parity: Even, Odd, or None selectable by parameter setting;
check sum method
Character transmission format Receiving: 11-bit, Sending: 12-bit
Order of bit transmission Least significant bit first
Frame length Variable to a maximum of 17 bytes
