Page #198 background imageLoading...
Page #198 background image
E6581158
H-2
8
(Continued)
Item displayed
Key
operated
LED
display
Communi-
cation No.
Description
Input terminal
___KK_KK
FE06
The ON/OFF status of each of the control signal
input terminals (F, R, RES, S1, S2, S3, VIB and
VIA) is displayed in bits.
ON:
OFF: _
Output terminal
_KK
FE07
The ON/OFF status of each of the control signal
output terminals (RY, OUT and FL) is displayed in
bits.
ON:
OFF: _
CPU1 version
X
FE08 The version of the CPU1 is displayed.
CPU2 version
XY
FE73 The version of the CPU2 is displayed.
Memory version
XG
FE09 The version of the memory mounted is displayed.
PID feedback F FE22
The PID feedback value is displayed. (Default set-
ting: unit Hz)
Frequency com-
mand value (PID-
computed)
D FE15
The PID-computed frequency command value is
displayed. (Default setting: unit Hz)
Integral input
power
M FE76
The integrated amount of power (kWh) supplied to
the inverter is displayed.
(0.01=1kWh, 1.00=100kWh)
Integral output
power
J FE77
The integrated amount of power (kWh) supplied
from the inverter is displayed.
(0.01=1kWh, 1.00=100kWh)
Rated current
C
FE70 The rated current of the inverter (A) is displayed.
Past trip 1
QE
FE10 Past trip 1 (displayed alternately)
Past trip 2
QJ
FE11 Past trip 2 (displayed alternately)
Past trip 3
QR
FE12 Past trip 3 (displayed alternately)
(Continued overleaf)
_KK
RY-RC
FL
OUT-NO
Note 6
Note 6
Note 7
Note 7
Note 4
Note 5
___KK_KK
VIA
VIB
S3
S2
F
R
RES
S1
Note 7
