Toshiba TOSVERT VF-S11 User Manual

E6581158
H-10
8
If H = : The bar representing OUT-NO is displayed.
If H = : The bar representing OUT-NO is not displayed.
Note 6: The integrated amounts of input and output power will be reset to zero, if you press and hold down the
key for 3 seconds or more when power is off or when the input terminal function CKWH (input ter-
minal function: 51) is turned on or displayed.
Note 7: Past rip records are displayed in the following sequence: 1 (latest trip record) ⇔2⇔3⇔4 (oldest trip rec-
ord). If no trip occurred in the past, the message “PGTT” will be displayed. Details on past trip record
1, 2, 3 or 4 can be displayed by pressing the key when past trip 1, 2, 3 or 4 is displayed. For more
information, see 8.1.2.
Note 8: The life alarm is displayed based on the value calculated from the annual average ambient temperature,
operation time and load current specified using H. Use this alarm as a guide only, since it is based
on a rough estimation.
Note 9: The cumulative operation time increments only when the machine is in operation.
Note 10: At the occurrence of a trip, maximum values are not always recorded and displayed for reasons of de-
tecting time.

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
