Toshiba TOSVERT VF-S11 User Manual

E6581158
J-7
10
No. Device Function and purpose
(11)
Parameter writer Note 1) Use this unit for batch read, batch copy, and batch writing of setting parameters.
(Model: PWU001Z)
(12)
Extension panel Note 1) Extended operation panel kit provided with LED indication section, RUN/STOP key,
UP/DOWN key, Monitor key, and Enter key.
(Model: RKP001Z)
(13)
Internal RS485
communication circuit
board
This unit allows you to connect a personal computer to multiple inverters for data transfer.
(Model: RS4003Z)
(14)
RS485 communication
converter unit Note 1)
This unit allows you to connect a personal computer to multiple inverters for data transfer.
(Models: RS4001Z, RS4002Z)
(15)
RS232C communication
converter unit
This unit allows you to connect a personal computer to inverters for data communications.
(Model: RS20035)
(16)
Remote panel This panel includes a frequency meter, a frequency regulator and RUN/STOP
(forward/reverse run)switches.
(Model: CBVR-7B1)
(17)
Application control unit The AP series of control units is available for the inverter to allow it to perform various
kinds of applied control. Contact your Toshiba representative for further information.
Note 1: Dedicated cables are needed to connect inverters to a personal computer.
Cable models: CAB0011 (1m)
CAB0013 (3m)
CAB0015 (5m)
Table for selection of optional external devices
Radio noise reduction filter
Voltage
class
Capacity of
applicable
motor
(kW)
Inverter model
Input AC
reactor
(Note 2)
DC
reactor
(Note 2)
High-
attenuation
type
Core type
(See Note 1.)
Braking
resistor
Motor-end
surge voltage
suppression
filter
EMC plate
(Note 3)
Foot-mounted filter
DIN
adapter
0. 2 VFS11S-2002PL PFL-2002S DCLS-2002 - RC5078 PBR-2007 - EMP003Z EMFS11S-2009AZ DIN003Z
0. 4 VFS11S-2004PL PFL-2005S DCL-2007 - RC5078 PBR-2007 - EMP003Z EMFS11S-2009AZ DIN003Z
0. 7 5 VFS11S-2007PL PFL-2011S DCL-2022 - RC5078 PBR-2007 - EMP003Z EMFS11S-2009AZ DIN003Z
1. 5 VFS11S-2015PL PFL-2018S DCL-2037 - RC5078 PBR-2022 - EMP004Z EMFS11S-2016BZ DIN005Z
Single-
phase
200V
class
2. 2 VFS11S-2022PL PFL-2018S DCL-2037 - RC5078 PBR-2022 - EMP004Z EMFS11S-2022CZ -
0. 2 VFS11-2002PM PFL-2001S DCL-2002 NF3005A-MJ RC5078 PBR-2007 EMP003Z EMFS11-2007AZ DIN003Z
0. 4 VFS11-2004PM PFL-2005S DCL-2007 NF3005A-MJ RC5078 PBR-2007 - EMP003Z EMFS11-2007AZ DIN003Z
0. 5 5 VFS11-2005PM PFL-2005S DCL-2007 NF3005A-MJ RC5078 PBR-2007 - EMP003Z EMFS11-2007AZ DIN003Z
0. 7 5 VFS11-2007PM PFL-2005S DCL-2007 NF3005A-MJ RC5078 PBR-2007 - EMP003Z EMFS11-2007AZ DIN003Z
1. 5 VFS11-2015PM PFL-2011S DCL-2022 NF3015A-MJ RC5078 PBR-2022 - EMP004Z EMFS11-4015BZ DIN005Z
2. 2 VFS11-2022PM PFL-2011S DCL-2022 NF3015A-MJ RC5078 PBR-2022 - EMP004Z EMFS11-4015BZ DIN005Z
3. 7 VFS11-2037PM PFL-2018S DCL-2037 NF3020A-MJ RC5078 PBR-2037 - EMP004Z EMFS11-4025CZ -
5. 5 VFS11-2055PM PFL-2025S DCL-2055 NF3030A-MJ RC9129 PBR3-2055 - EMP005Z EMFS11-4047DZ -
7. 5 VFS11-2075PM PFL-2050S DCL-2110 NF3040A-MJ RC9129 PBR3-2075 - EMP005Z EMFS11-4047DZ -
11 VFS11-2110PM PFL-2050S DCL-2110 NF3050A-MJ RC9129 PBR3-2110 - EMP006Z EMFS11-2083EZ -
Single-
Phase
200V
class
15 VFS11-2150PM PFL-2100S DCL-2220 NF3080A-MJ RC9129 PBR3-2150 EMP006Z EMFS11-2083EZ -
0.4 VFS11-4004PL PFL-4012S DCL-2007 NF3010C-MJ RC5078 PBR-2007 MSF-4015Z EMP004Z EMFS11-4015BZ DIN005Z
0.75 VFS11-4007PL PFL-4012S DCL-2007 NF3010C-MJ RC5078 PBR-2007 MSF-4015Z EMP004Z EMFS11-4015BZ DIN005Z
1.5 VFS11-4015PL PFL-4012S DCL-2007 NF3010C-MJ RC5078 PBR-2007 MSF-4015Z EMP004Z EMFS11-4015BZ DIN005Z
2.2 VFS11-4022PL PFL-4012S DCL-2022 NF3010C-MJ RC5078 PBR-2007 MSF-4037Z EMP004Z EMFS11-4025CZ -
3.7 VFS11-4037PL PFL-4012S DCL-2022 NF3010C-MJ RC5078 PBR-4037 MSF-4037Z EMP004Z EMFS11-4025CZ -
5.5 VFS11-4055PL PFL-4025S DCL-4110 NF3015C-MJ RC9129 PBR3-4055 MSF-4075Z EMP005Z EMFS11-4047DZ -
7.5 VFS11-4075PL PFL-4025S DCL-4110 NF3020C-MJ RC9129 PBR3-4075 MSF-4075Z EMP005Z EMFS11-4047DZ -
11 VFS11-4110PL PFL-4025S DCL-4110 NF3030C-MJ RC9129 PBR3-4110 MSF-4150Z EMP006Z EMFS11-4049EZ -
Single-
Phase
400V
class
15 VFS11-4150PL PFL-4050S DCL-4220 NF3040C-MJ RC9129 PBR3-4150 MSF-4150Z EMP006Z EMFS11-4049EZ -
Note 1: This filter is used wound around the input-side power line. (Number of turns: 4 or more) This filter can
be installed on the output side, as well.
Note 2: Connecting this reactor to the inverter makes it compliant with the standard "General Inverter (input
current of 20A or less) Harmonic Suppression Measures Execution Guidelines" set by the Japan Elec-
tric Industry Association.
Note 3: EMC plate is attached as standard.

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
