E6581158
K-9
11
• Torque boost parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0: Auto-tuning disabled
1: Initialization of H (reset to 0)
H
0400 Auto-tuning - -
2: Auto-tuning enabled
(after execution: 0)
0
H
0401 Slip frequency
gain
% 1/1 0-150 50
H
0402 Motor constant #1
(primary
resistance)
% 0.1/0.1 0.0-30.0 * 1
H
0415 Motor rated
current
A 0.1/0.1 0.1-100.0 * 1
H
0416 Motor no-load
current
% 1/1 10-90 * 1
H
0417 Motor rated speed min-1 1/1 100-32000 1410(WP)
1710
(WN, AN)
H
0418 Speed control
response
coefficient
- 1/1 1-150 40
H
0419 Speed control
stability coefficient
- 1/1 1-100 20
H
0480 Exciting strength-
ening coefficient
% 1/1 100-130 100
H
0485 Stall cooperation
gain at field
weakening zone 1
- 1/1 10-250 100
H
0492 Stall cooperation
gain at field
weakening zone 2
- 1/1 50-150 100
H
0494 Motor adjustment
factor
- 1/1 0-200 * 1
6.17
*1 : Default values vary depending on the capacity. See the table of page K-14.
• Acceleration/deceleration time parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H
0500 Acceleration time
2
s 0.1/0.1 0.0-3200 10.0
H
0501 Deceleration time
2
s 0.1/0.1 0.0-3200 10.0
H
0502 Acceleration/decel
eration 1 pattern
-- 0
H
0503 Acceleration/decel
eration 2 pattern
--
0: Linear
1: S-pattern 1
2: S-pattern 2
0
H
0504 Acceleration/decel
eration selection
(1, 2 , 3)
- - 1: Acceleration/deceleration 1
2: Acceleration/deceleration 2
3: Acceleration/deceleration 3
1
H
0505 Acceleration/decel
eration 1 and 2
switching
frequency
Hz 0.1/0.０10.0-WN 0.0
H
0506 S-pattern lower-
limit adjustment
amount
% 1/1 0-50 10
6.18
