Toshiba TOSVERT VF-S11 User Manual

E6581158
K-10
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H
0507 S-pattern upper-
limit adjustment
amount
% 1/1 0-50 10
H
0510 Acceleration time
3
s 0.1/0.1 0.0-3200 10.0
H
0511 Deceleration time
3
s 0.1/0.1 0.0-3200 10.0
H
0512 Accelera-
tion/deceleration 3
pattern
- - 0: Linear
1: S-pattern 1
2: S-pattern 2
0
H
0513 Accelera-
tion/deceleration 2
and 3 switching
frequency
Hz 0.1/0.01 0.0-WN 0.0
6.18
• Protection parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H
0601 Stall prevention
level 1
%
(A)
1/1
10-199，
200 (disabled)
150
6.19.2
H
0602
Inverter trip
retention selection
- - 0: Canceled with the power off
1: Still retained with the power off
0 6.19.3
H
0603 Emergency stop
selection
- - 0: Coast stop
1: Slowdown stop
2: Emergency DC braking
0
6.19.4
H
0604 Emergency DC
braking time
s
0.1/0.1 0.0-20.0
1.0
6.19.4
H
0605
Output phase
failure detection
mode selection
-
-
0: Disabled
1: At start-up (only one time after
power is turned on)
2: At start-up (each time)
3: During operation
4: At start-up + during operation
5: Detection of cutoff on output side
0
6.19.5
H
0607 Motor 150%-
overload time limit
s 1/1 10-2400 300 6.19.1
H
0608 Input phase failure
detection mode
selection
- - 0: Disabled, 1: Enabled 1 6.19.6
H
0610 Low current
trip/alarm
- - 0: Alarm only
1: Tripping
0
H
0611 Small current
detection current
%
1/1 0-100 0
H
0612 Small current
detection time
s 1/1 0-255 0
6.19.7
H
0613 Detection of
output short-circuit
during start-up
- - 0: Each time (standard pulse)
1: At start-up (only one time after
power is turned on)
(standard pulse)
2: Each time (short-time pulse)
3: At start-up (only one time after
power is turned on)
(short-time pulse)
0 6.19.8
H
0615 Over-torque
trip/alarm
selection
- - 0: Alarm only
1: Tripping
0
H
0616 Over-torque
detection level
%
1/1 0-250 150
H
0618 Over-torque
detection time
s 0.1/0.1 0.0-10.0 0.5
6.19.9

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
