6 Commissioning
6.1 Device description file
The XML file contains all information on the measuring system-specific parameters
and the operating modes of the measuring system. The XML file is integrated by the
EtherCAT network configuration tool, in order to enable correct configuration and
commissioning of the measuring system.
The XML file is called "TR-ETHERCAT-DEVICES_V00X.XML" and is located
on software/support CD art. no.: 490-01001 --> soft no.: 490-00423.
6.1.1 Device groups
The XML file contains several device groups and device types. Therefore for rotative
measuring systems the device group "TR-Rotative" must be selected. Under the
device group the individual device types with the appropriate objects are arranged,
which can be different in the number of bits and the bit length. The device type must
be selected according to the name plate:
TR-Rotative
├ ...
│ ├ ...
│ ├ ...
│ ├ ...
├ CEx-58x
│ ├ 1000
│ ├ 1008
│ ├ 1009
│ ├ 100A
│ ├ 1018
│ ├ 1A00
│ ├ 1A01
│ ├ 1C00
│ ├ 1C13
│ ├ 1C33
│ ├ 2000
│ ├ 2001
│ ├ 3101
│ ├6000
│ ├ 6001
│ ├ 6002
│
├ 6003
│ ├ ...
