8.6 Object 1A00h: 1
st
Transmit PDO Mapping
The following process data can be transmitted with the first Transmit Process Data
Object 0x1A00:
● Status, Object 3101, Input --> Sub-Index 1
● Position, Object 3101, Input --> Sub-Index 2
The assignment of whether object 0x1A00 is actually transmitted as process data is made
via object "Object 1C13h: Sync Manager Channel 3 (process data input)" page 103.
Index 0x1A00
Name
TxPDO 1 Normal mapping
Object code
RECORD
Data type
PDO_MAPPING
Category
Mandatory for each supported TxPDO
Sub-Index 0
Description
Number of mapped objects in the PDO
Data type
UNSIGNED8
Category
Mandatory
Access
ro
PDO mapping
No
Value
2
Sub-Index 1
Description
Input, Status
Data type
UNSIGNED32
Category
Conditional
Access
ro
PDO mapping
No
Value
Bit 0-7: Length of the mapped object in bits = 8
Bit 8-15: Sub-index of the mapped object = 1
bit 16-31: Index of the mapped object = 3101
