9-Transact Template Language Epic Edge™ OEM Integration Manual
Page 148 August 2018 100-14444 Rev B
Predefined
Region 14
Setup for numeric dollar amount field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<x22> Select character size = 3W/3H
[ESC]G<1> Set emphasized print
[GS]$<1><194> Set absolute vertical position = 450
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
Follow with dynamic text, terminated with [CR]
Predefined Region 15
Setup for Voucher void after field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<0> Clear emphasized print
[GS]$<1><215> Set absolute vertical position = 471
[GS]F<2><0><50><1><124> Set field (Right, 50, 380)
Voucher void after[CR] Predefined text, terminate field with [CR]
Predefined Region 16
Setup for void after time field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<0> Clear emphasized print
[GS]$<1><215> Set absolute vertical position = 471
[GS]F<0><1><134><2><68> Set field (Left, 390, 580)
Follow with dynamic text, terminated with [CR]
Predefined Region 17
Setup for machine
number field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<0> Clear emphasized print
[GS]$<1><215> Set absolute vertical position = 471
[GS]F<0><2><96><3><192> Set field (Left, 608, 960)
Follow with dynamic text, terminated with [CR]
