9-Transact Template Language Epic Edge™ OEM Integration Manual
100-14444 Rev B August 2018 Page 149
Predefined Region 18
Setup for centered barcode field
Command Sequence
Explanation
[ESC]t<3> Set Print Direction in page mode = D
[ESC]G<0> Clear emphasized print
[GS]$<0><220> Set absolute vertical position = 220
[GS]A<0><240> Starting Position of Bar Code = 240
[GS]W<4><8> Set Bar Code Element Width Thin = 4, Thick =
8
[GS]h<100> Set Bar Code Height = 100
[GS]k<7><18> Print Bar Code (Interleaved 2 of 5, 18
characters)
Follow with 18 bar code data characters!
Predefined Region 19
Setup for “JACKPOT RECEIPT” field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<x33> Select character size = 4W/4H
[ESC]G<1> Set emphasized print
[GS]$<0><170> Set absolute vertical position = 170
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
JACKPOT RECEIPT[CR] Predefined text, terminate field with [CR]
Predefined
Region 20
Setup for numeric dollar amount field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<x22> Select character size = 3W/3H
[ESC]G<1> Set emphasized print
[GS]$<0><220> Set absolute vertical position = 220
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
Follow with dynamic text, terminated with [CR]
Predefined Region 21
Setup for alpha dollar amount field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<0> Select print mode = 10x24, 20 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<0> Clear emphasized print
[GS]$<0><240> Set absolute vertical position = 240
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
Follow with dynamic text, terminated with [CR]
