9-Transact Template Language Epic Edge™ OEM Integration Manual
Page 150 August 2018 100-14444 Rev B
Predefined Region 22 Setup for continued alpha dollar amount
field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<0> Select print mode = 10x24, 20 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<0> Clear emphasized print
[GS]$<1><4> Set absolute vertical position = 260
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
Follow with dynamic text, terminated with [CR]
Predefined Region 23
Setup for date field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<2> Select print mode = 13x24, 14 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><40> Set absolute vertical position = 296
[GS]F<1><0><180><1><144> Set field (Center, 180, 400)
Follow with dynamic text, terminated with [CR]
Predefined Region 24
Setup for time field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<2> Select print mode = 13x24, 14 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><40> Set absolute vertical position = 296
[GS]F<1><1><149><2><83> Set field (Center, 405, 595)
Follow with dynamic text, terminated with [CR]
Predefined
Region 25
Setup for ticket number field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<2> Select print mode = 13x24, 14 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><40> Set absolute vertical position = 296
[GS]F<0><2><88><3><192> Set field (Left, 600, 960)
Follow with dynamic text, terminated with [CR]
