9-Transact Template Language Epic Edge™ OEM Integration Manual
100-14444 Rev B August 2018 Page 151
Predefined Region 26
Setup for “VALIDATION” field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<3> Select print mode = 14x24, 12 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><80> Set absolute vertical position = 336
[GS]F<0><0><200><1><154> Set field (Left, 200, 410)
VALIDATION[CR] Predefined text, terminate field with [CR]
Predefined Region 27
Setup for validation number field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<3> Select print mode = 14x24, 12 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><80> Set absolute vertical position = 336
[GS]F<0><1><164><3><192> Set field (Left, 420, 960)
Follow with dynamic text, terminated with [CR]
Predefined Region 28
Setup for offset barcode field
Command Sequence
Explanation
[ESC]t<3> Set Print Direction in page mode = D
[ESC]G<0> Clear emphasized print
[GS]$<0><45> Set absolute vertical position = 45
[GS]A<0><240> Starting Position of Bar Code = 240
[GS]W<4><8> Set Bar Code Element Width Thin = 4, Thick =
8
[GS]h<100> Set Bar Code Height = 100
[GS]k<7><18> Print Bar Code (Interleaved 2 of 5, 18
characters)
Follow with 18 bar code data characters!
Predefined Region 29
Setup for “VOID DEMO VOID” field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<x33> Select character size = 4W/4H
[ESC]G<1> Set emphasized print
[GS]$<0><170> Set absolute vertical position = 170
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
VOID DEMO VOID[CR] Predefined text, terminate field with [CR]
