9-Transact Template Language Epic Edge™ OEM Integration Manual
Page 152 August 2018 100-14444 Rev B
Predefined Region 30
Setup for 1st “VOID VOID VOID VOID” field
Command Sequence
Explanation
[ESC]t<0> Set Print Direction in page mode = A
[ESC]!<0> Select print mode = 10x24, 20 CPI
[GS]!<x11> Select character size = 2W/2H
[ESC]G<1> Set emphasized print
[GS]$<0><25> Set absolute vertical position = 25
[GS]F<1><0><0><0><0> Set field (Center, 0, 0)
VOID VOID VOID VOID[CR] Predefined text, terminate field with [CR]
Predefined Region 31 Setup for 2nd “VOID VOID VOID VOID”
field
Command Sequence
Explanation
[ESC]t<0> Set Print Direction in page mode = A
[ESC]!<0> Select print mode = 10x24, 20 CPI
[GS]!<x11> Select character size = 2W/2H
[ESC]G<1> Set emphasized print
[GS]$<0><75> Set absolute vertical position = 75
[GS]F<1><0><0><0><0> Set field (Center, 0, 0)
VOID VOID VOID VOID[CR] Predefined text, terminate field with [CR]
Predefined Region 32
Setup for 3rd “VOID VOID VOID VOID” field
Command Sequence
Explanation
[ESC]t<0> Set Print Direction in page mode = A
[ESC]!<0> Select print mode = 10x24, 20 CPI
[GS]!<x11> Select character size = 2W/2H
[ESC]G<1> Set emphasized print
[GS]$<0><125> Set absolute vertical position = 125
[GS]F<1><0><0><0><0> Set field (Center, 0, 0)
VOID VOID VOID VOID[CR] Predefined text, terminate field with [CR]
Predefined Region 33
Setup for 4th “VOID VOID VOID VOID” field
Command Sequence
Explanation
[ESC]t<0> Set Print Direction in page mode = A
[ESC]!<0> Select print mode = 10x24, 20 CPI
[GS]!<x11> Select character size = 2W/2H
[ESC]G<1> Set emphasized print
[GS]$<0><175> Set absolute vertical position = 175
[GS]F<1><0><0><0><0> Set field (Center, 0, 0)
VOID VOID VOID VOID[CR] Predefined text, terminate field with [CR]
