9-Transact Template Language Epic Edge™ OEM Integration Manual
100-14444 Rev B August 2018 Page 153
Setup for 5th “VOID VOID VOID VOID” field
[ESC]t<0> Set Print Direction in page mode = A
[ESC]!<0> Select print mode = 10x24, 20 CPI
[GS]!<x11> Select character size = 2W/2H
[ESC]G<1> Set emphasized print
[GS]$<0><225> Set absolute vertical position = 225
[GS]F<1><0><0><0><0> Set field (Center, 0, 0)
VOID VOID VOID VOID[CR] Predefined text, terminate field with [CR]
Setup for 6th “VOID VOID VOID VOID
[ESC]t<0> Set Print Direction in page mode = A
[ESC]!<0> Select print mode = 10x24, 20 CPI
[GS]!<x11> Select character size = 2W/2H
[ESC]G<1> Set emphasized print
[GS]$<1><19> Set absolute vertical position = 275
[GS]F<1><0><0><0><0> Set field (Center, 0, 0)
VOID VOID VOID VOID[CR] Predefined text, terminate field with [CR]
Setup for large “VOID” field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<3> Select print mode = 14x24, 12 CPI
[GS]!<x77> Select character size = 8W/8H
[ESC]G<1> Set emphasized print
[GS]$<1><80> Set absolute vertical position = 336
[GS]F<0><0><0><2><188> Set field (Left, 0, 700)
VOID[CR] Predefined text, terminate field with [CR]
Setup for “CASHOUT RECEIPT” field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<x33> Select character size = 4W/4H
[ESC]G<1> Set emphasized print
[GS]$<0><170> Set absolute vertical position = 170
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
CASHOUT RECEIPT[CR] Predefined text, terminate field with [CR]
Setup for dynamic banner text field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<x33> Select character size = 4W/4H
[ESC]G<1> Set emphasized print
[GS]$<0><170> Set absolute vertical position = 170
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
Follow with dynamic text, terminated with [CR]
