9-Transact Template Language Epic Edge™ OEM Integration Manual
Page 154 August 2018 100-14444 Rev B
Predefined Region 39 Setup for dynamic text under bar code
field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><50> Set absolute vertical position = 306
[GS]F<0><0><200><1><154> Set field (Left, 200, 410)
Follow with dynamic text, terminated with [CR]
Predefined
Region 40
Setup for dynamic ticket valid time field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<0> Clear emphasized print
[GS]$<1><215> Set absolute vertical position = 471
[GS]F<1><0><50><2><68> Set field (Center, 50, 580)
Follow with dynamic text, terminated with [CR]
Predefined Region 41
Setup for dynamic validation header field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<3> Select print mode = 14x24, 12 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><80> Set absolute vertical position = 336
[GS]F<0><0><200><1><154> Set field (Left, 200, 410)
Follow with dynamic text, terminated with [CR]
Predefined Region 42
Setup for “JACKPOT VOUCHER” field
Command Sequence
Explanation
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<x33> Select character size = 4W/4H
[ESC]G<1> Set emphasized print
[GS]$<0><170> Set absolute vertical position = 170
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
JACKPOT VOUCHER[CR] Predefined text, terminate field with [CR]
