Spare parts

122 T2-C User Guide

Circuit boards

10003077 T2 Dual Pinch Valve

10003078 T2 Peristaltic Pump w/ Holder

10003346 T2 Maintenance Cradle

10003079 T2 Assy Lifter Motor with Cover

10003615 Assy Sled Motor with Cover

10002080 T2 Gear Cam Lift

10003357 T2 Module Wiper Transfer Gen 2

T2ENGINE Complete Engine (Trojanlabel)

Part Number Description

T1004.03 Web path controller board

T1005.04 BLDC driver

T1006.02 Step driver

T1007.02 Rotary sensor

T1008.02 Edge Sensor

T1009.03 E-Stop

T1010.01 QA Board

T1011.01 Connector PCA

T1012 Ink Board

T1013 Reservoir Sensor PCA

T1014 Temp sensor

T2-ECM-USB PC Motherboard-sub board

T2-ECM PC Motherboard

Default Chapter7
- Table of Contents7
Chapter 1: Introduction11
- General Information11
Introduction11
- Overview and Application12
Chapter 2 Setting up the T2-C Press17
- Cabling (Network and Power Supply)18
- Physical Setup17
Chapter 3: Power on19
Power on19
- Power on Process19
- Visible Safety Check19
- Installing Ink Tanks and the Printhead20
Chapter 4 Loading the Label Material29
- Unwinder and Rewinder Roll Direction29
  - Rolling Direction Unwinder - Ink Jet Coating on the Inside or Outside29
  - Rolling Direction Rewinder30
- Threading the Label Material from Scratch31
- Adjusting the Label Edge Sensor35
- Calibrate Tension for the Label Web35
- Splicing and Changing the Label Roll37
Chapter 5 Select and Queue Print / Start Print Job39
Chapter 6 Pause, Resume, or Stop a Print Job41
Chapter 7 Moving the Label Web43
Chapter 8: Printing Modes45
- Continuous Printing Mode45
Printing Modes45
- Die-Cut Printing Mode46
  - Calibrating the Label Gap Sensor46
- Blackmark Printing Mode48
  - Calibrating the Label Gap/Blackmark Sensor48
- Gap Size and Speeds50
Chapter 9 Shutting down the T2-C Press51
Chapter 10: Driver Installation and Features53
- Driver Installation53
Driver Installation and Features53
- Driver Features and Functions56
  - General Driver Settings57
  - Integrating Additional Color Profiles59
Chapter 11: User Interface (UI)61
- Right Side Status Bar61
User Interface (UI)61
- General Settings (HOME Tab)62
- T2-C Press Handling Menus (Trojantwo Tab)74
Chapter 12: Updating Software and Firmware89
Updating Software and Firmware89
- Updating Via the Online Updater89
- Updating Via the Offline Updater90
- Purpose93
- Usage93
Using the Built in Slitter for the T2-C Press93
Chapter 13: Using the Built in Slitter for the T2-C Press94
- Replacing the Slitter Blades95
Chapter 14: Maintenance97
- Cleaning Other Rollers99
- Emptying the Waste Ink Bottle99
Maintenance97
- Regular Cleaning/Checking Tasks97
  - Cleaning the NIP Roller97
- Replacing the Wiper Roller101
- Manual Printhead Wiping105
- Clean or Replace Aerosol Filter108
Preparing the T2-C Press for Transportation109
- Removing the Printhead109
Chapter 15: Preparing the T2-C Press for Transportation110
- Storing Used or Opened Printheads110
- Removing the Ink from the Reservoir Ink Tanks111
- Removing the Ink from the Ink Filters112
- Empty and Clean the Waste Ink Bottle113
- Removing the Ink Tanks113
Chapter 16: Troubleshooting115
- Error States115
Troubleshooting115
- Error Messages on Screen119
Appendix A: Spare Parts121
- Consumables121
- Print Engine121
- Circuit Boards122
- Tubes, Cables, and Other Parts123
Index125
