T2-C User Guide 121

Spare parts

Consumables

Print engine

Part Number Description

20010006 Printhead LL2X

30010031 2L Ink Tank Trojan N Cyan

30010032 2L Ink Tank Trojan N Magenta

30010033 2L Ink Tank Trojan N Yellow

30010034 2L Ink Tank Trojan N Black

10003356 T2 Wiper Roller Gen 2 (Micro Fiber Roller)

10000036 Slitter blade set (6 blades)

Aerosol filter

Part Number Description

10004022 MPCA TROJAN

10004024 MPCA TROJAN, VOLUME PRESS

10003074 Assy DPCA with Holder

10003075 Pen Driver PCA

10003076 T2 Assy Cartridge Locator

10002078 Assy Dock Fluidic Pump Side (Revolver -

closest to ink connectors)

10002079 Assy Dock Fluidic Valve Side (Revolver -

Farthest from ink connectors)

10002014 Lever Latch (Plastic PH cover)

10002015 Lever Latch Spring (10 pieces)

Default Chapter7
- Table of Contents7
Chapter 1: Introduction11
- General Information11
Introduction11
- Overview and Application12
Chapter 2 Setting up the T2-C Press17
- Cabling (Network and Power Supply)18
- Physical Setup17
Chapter 3: Power on19
Power on19
- Power on Process19
- Visible Safety Check19
- Installing Ink Tanks and the Printhead20
Chapter 4 Loading the Label Material29
- Unwinder and Rewinder Roll Direction29
  - Rolling Direction Unwinder - Ink Jet Coating on the Inside or Outside29
  - Rolling Direction Rewinder30
- Threading the Label Material from Scratch31
- Adjusting the Label Edge Sensor35
- Calibrate Tension for the Label Web35
- Splicing and Changing the Label Roll37
Chapter 5 Select and Queue Print / Start Print Job39
Chapter 6 Pause, Resume, or Stop a Print Job41
Chapter 7 Moving the Label Web43
Chapter 8: Printing Modes45
- Continuous Printing Mode45
Printing Modes45
- Die-Cut Printing Mode46
  - Calibrating the Label Gap Sensor46
- Blackmark Printing Mode48
  - Calibrating the Label Gap/Blackmark Sensor48
- Gap Size and Speeds50
Chapter 9 Shutting down the T2-C Press51
Chapter 10: Driver Installation and Features53
- Driver Installation53
Driver Installation and Features53
- Driver Features and Functions56
  - General Driver Settings57
  - Integrating Additional Color Profiles59
Chapter 11: User Interface (UI)61
- Right Side Status Bar61
User Interface (UI)61
- General Settings (HOME Tab)62
- T2-C Press Handling Menus (Trojantwo Tab)74
Chapter 12: Updating Software and Firmware89
Updating Software and Firmware89
- Updating Via the Online Updater89
- Updating Via the Offline Updater90
- Purpose93
- Usage93
Using the Built in Slitter for the T2-C Press93
Chapter 13: Using the Built in Slitter for the T2-C Press94
- Replacing the Slitter Blades95
Chapter 14: Maintenance97
- Cleaning Other Rollers99
- Emptying the Waste Ink Bottle99
Maintenance97
- Regular Cleaning/Checking Tasks97
  - Cleaning the NIP Roller97
- Replacing the Wiper Roller101
- Manual Printhead Wiping105
- Clean or Replace Aerosol Filter108
Preparing the T2-C Press for Transportation109
- Removing the Printhead109
Chapter 15: Preparing the T2-C Press for Transportation110
- Storing Used or Opened Printheads110
- Removing the Ink from the Reservoir Ink Tanks111
- Removing the Ink from the Ink Filters112
- Empty and Clean the Waste Ink Bottle113
- Removing the Ink Tanks113
Chapter 16: Troubleshooting115
- Error States115
Troubleshooting115
- Error Messages on Screen119
Appendix A: Spare Parts121
- Consumables121
- Print Engine121
- Circuit Boards122
- Tubes, Cables, and Other Parts123
Index125
