■ Descriptions related to OUT data
○ Write data
Used when writing data using a command request. The write data is configured with a 32-bit binary (2
words) and the order of HI and LO positions changes with the DWORD mode of F701+ (setting mode
6-1).
○ Command no.
When writing data, specify the command no. for the data to specify. Upper byte is not used. Refer to
the list below for command no. Ple
ase note that both the command no. response and the read data will
be turned OFF and the command response will be turned ON for invalid command no. In addition, data
cannot be written in while LOCK is ON. (In this case, the command response returns ON.)
Setting value Command no. Input range Writing prohibited
Upper limit 1 0 to 99999
Lower limit 2 0 to 99999
Near zero 3 0 to 99999
Set point 1 4 0 to 99999
Set point 2 5 0 to 99999
Compensation 6 0 to 9999
Over 7 0 to 9999
Under 8 0 to 9999
Final 9 0 to 99999
Comparison inhibit time 11 0 to 999
Judging time 12 0 to 99
Complete output time 13 0 to 99
Compensation feeding time 14 0 to 999
Number of times for AZ 15 0 to 99
Number of times for Judging 16 0 to 99
Auto free fall compens
ation
regulation value
17 0 to 99999
Tare setting 19 0 to 99999
Weighing function 1 21 0000 to 2224
Weighing function 2 22 00000 to 21312
Weighing function 3 23 0000 to 3191
Sequence mode 24 0000 to 2111
Function key inhibited 25 0000 to 1111
Filter 26 00 to 73
Motion detect 27 00-00 to 99-99
Zero tracking 28 00-00 to 99-99
Setting value LOCK 29 00 to 11
Balance weight value 31 0 to 99999
Capacity 32 1 to 99999
Min. scale division 33 1 t
o 100
Net over 34 0 to 99999
Gross over 35 0 to 99999
DZ regulation value 36 0 to 9999
Function selection 37 0000 to 3315
Compensation for gravitational
acceleration
38 97500 to 98500
Option substrate 39 00000 to 11111
D/A output mode 41 00 to 21
D/A zero output weight value 42 0 to 99999
D/A full scale setting 43 1 to 99999
