13
2 Key Operation
13
Key Operation
Chapter
2
2-1. Front panel and setting mode configuration chart
The setting keys consist of nine setting modes. In each setting mode, one function is assigned to each of
keys 1 to 9.
Chart 1:Setting mode configuration chart
Setting item keys
1 2 3 4 5 6 7 8 9 ZERO
Setting
mode 0
Upper limit
(P.14)
Lower limit
(P.14)
Near zero
(P.14)
Set point 1
(P.14)
Set point 2
(P.14)
Compensation
(P.14)
Over
(P.14)
Under
(P.14)
Final
(P.14)
----
Setting
mode 1
Comparison
inhibit time 1
(P.33)
Judging time
(P.33)
Complete
output time
(P.33)
Compensation
feeding time
(P.35)
Number of
times for AZ
(P.34)
Number of
times for
judging
(P.34)
Auto free fall
compensation
regulation
(P.31)
Comparison
inhibit time 2
(P.33)
Tare setting
(P.27)
----
Setting
mode 2
Weighing
function 1
(P.29, 31, 32)
Weighing
function 2
(P.32, 33, 37)
Weighing
function 3
(P.31)
Sequence
mode
(P.29, 35)
Function key
inhibited
(P.60)
Filter
(P.23)
Motion
detection
(P.24)
Zero tracking
(P.25)
Setting value
LOCK
(P.19)
----
Setting
mode 3
Balance
weight value
(P.19)
Capacity
(P.19)
Min. scale
division
(P.19)
Net over
(P.131)
Gross over
(P.131)
DZ regulation
value
(P.26)
Function
selection
(P.19, 21, 23)
Compensation
for gravitational
acceleration
(P.20)
Option
substrate
(P.60)
----
Setting
mode 4
DA output
mode
(P.104)
DA zero
output weight
(P.104)
DA full scale
setting
(P.104)
RS-232C/
RS-485 I/F
setting
(P.65, 74)
ID setting
(0000)
(P.74)
Transmission
delay time
(P.75)
Extended
function
selection 1
(P.24)
Moving
average filter
(P.24)
Measurement
Act compliance
(P.27)
----
Setting
mode 5
Input
selection
(P.37)
Output
selection
(P.37)
Restart
setting
set point 1
(P.36)
Restart
setting
set point 2
(P.36)
Restart
setting
set point 3
(P.36)
Number of
times for
knocking
(P.35)
Knocking
period
(P.35)
Number of
digits for
accumulated
display
(P.124)
Automatic
filter
adjustment
(P.23)
----
Setting
mode 6
PROFIBUS
 I/F setting
(P.106)
PROFIBUS
baud rate
display
(P.106)
PROFIBUS
station No.
(P.106)
---- ---- ---- ---- ---- ---- ----
Setting
mode 7
Print settings
(P.118)
Printer
command
(P.118)
Printer
settings
(P.119)
Individual
print format
(P.119)
Total print
format
(P.119)
Print count
(P.120)
Year settings
(P.120)
Date settings
(P.120)
Time settings
(P.120)
----
Setting
mode 8
Average
weight
(P.123)
Max. weight
(P.123)
Min. weight
(P.123)
General
standard
deviation
(P.123)
Sample
standard
deviation
(P.123)
Number of
data
(P.123)
Latest data
(P.123)
Maximum -
Minimum
(P.123)
Accumulated
value
(P.124)
Setting
mode 9
Span
calibration
(P.21)
Equivalent
calibration
(P.22)
---- ---- ---- ---- ----
A/D
conversion
speed
(P.61)
Password
(P.60)
Zero
calibration
(P.21)
2 Key Operation
(1) Number
(5) Designated
(2) Units
(3) Status
(4) Setting
keys
display
display
display
keys
