12
1 Before Getting Started
12
Before Getting Started
Chapter
1
1-12. Protective grounding connection
The grounding pole for the input connector of the AC power supply is the protective grounding.
1-13. Frame grounding connection
This grounding terminal is used to prevent problems arising from noise and so forth.
Use a thick electric wire (approx. 0.75 mm
2
) and be sure to perform grounding.
Warning
- The rating of the AC cable included is AC125V, 10A. Prepare a separate AC cable if
the product is used at a voltage higher than the rating or is used overseas.
- Be sure to ground the protective grounding.
- Be sure to install and fix the F701+ to a panel and so forth. Install a breaker so that an
operator can turn power OFF immediately, and place an appropriate indication showing
the breaker ins
tallation.
Warning
- Connect the product when power is OFF in order to prevent electric shock.
- Be sure to ground the frame grounding terminal to prevent problems arising from noise
and so forth. (The case and frame grounding terminal are in continuity.)
- Do not use screws other than those used for attaching the main body.
To Next Page
