RS-485 communication interface (485)
Description
This interface enables a longer distance communication compared to
RS-232C. Furthermore, multiple F701+ units can be connected in
parallel by setting ID nos.
Signal level RS-485 compliant
Transmitting distance Approx. 1km
Transmitting method Asynchronous, half duplex
Transmitting speed Select from 4800, 9600, 19
200, 38400, 57600, 115.2kbps
Bit configuration
Start bit: 1 bit
Character length: Select from 7 or 8 bits
Stop bit: Select from 1 or 2 bits
Parity bit: Select from none, odd, even
Code
ASCII (for UNI-Format)
Binary (for Modbus-RTU)
PROFIBUS interface (PRF)
Description
This interface can be connected as a slave device for PROFIBUS field
bus.
Standards PROFIBUS-DPVO
Communication speed
Supports 9.6kbps to 12Mbps (a
utomatic following)
(Please note that 45.45kbps is not supported)
Occupying memory OUT/12 bytes (6 words), IN/26 bytes (13 words)
Station no. 0 to 125
GSD file name UNIP0DC4.GSD
Code ASCII
Remarks
Supports Sync Mode and Freeze Mode
Does not support Special Clear Mode (Fail Safe Mode)
Power supply voltage AC100 to 240V (+10% -15%) [free power supply 50/60Hz]
Power consumption 7W typ. (11W max)
Operating conditions
T
emperature: Operating temperature range -10 to +40°C
Storage temperature range -20 to +85°C
Humidity: 85%RH or less (no condensation)
External dimensions 192W x 96H x 140D (mm) (not including protruding sections)
Panel cutout size 186W x 92H (mm)
Weight Approx. 1.5kg
AC input cord (2m) 1
Small screwdriver for connection of terminal block 1
Load cell connector 1
CONTROL terminal connector 1
F701+ operation manual 1
