5 Timing Chart for Weighing
44
Timing Chart for Weighing
Chapter
5
An example of a timing chart for simple comparison control and sequence control.
5-1. Simple comparison control
This setting is used to control or judge final discharge.
5 Timing Chart for Weighing
Near zero
Final - Set point 1
Final - Set point 2
Final - Compensation
Final
NET
Time
SP1
㸦output㸧
SP2
㸦output㸧
SP3
㸦output㸧
Comparison inhibit timer
Judging timer
Stable
㸦output㸧
Over
㸦output㸧
t0 t1
t2
Near zero
㸦output㸧
Over
Under
*1
*2
*3
*5
Complete timer
t3
Complete
㸦output㸧
Go
㸦output㸧
Under
㸦output㸧
ON
OFF
ON
ON
ON
ON
ON
OFF
ON
No.2
No.1
No.3
No.4
No.5
No.6
No.7
*4
No.8
No.9
25% of final
*6
*7
t0: comparison inhibit time 1
t1: comparison inhibit time 2
t2: judging time
t3: complete output time
SP1: set point 1
SP2: set point 2
SP3: set point 3
