Unipulse F701+ User Manual

43
4 Performing Final Discharge Control
43
Performing Final Discharge
Chapter
4
Weight error
Output turns ON when display is ±LOAD, OFL or ZALM (zero error).
(Refer to P.125 "7-1.Over-scale display" for details regarding error display.)
Seq. error
Output turns ON in seq. error.
(Refer to P.126 "7-2.Sequence error display" for details regarding seq. error.)
RUN Output turns ON when normal operation is performed.
Paused Output turns ON when paused.
Waiting for judging input
Output turns ON while waiting for judging input when "comparison is m
ade when
external judging input is ON" during sequence mode.
Knocking
Output turns ON during knocking operation if number of times for knocking and
knocking time are set.
Signal Explanation
