Unipulse F701+ User Manual

52
5 Timing Chart for Weighing
52
Timing Chart for Weighing
Chapter
5
5-5. Sequence control (with pause input/power failure restoration) [CASE 1]
Near zero
Final - Set point 2
Final - Set point 1
Final - Compensation
Final
NET
Time
Tare
subtraction
㸦input㸧
Start
㸦input㸧
SP1
㸦output㸧
SP2
㸦output㸧
SP3
㸦output㸧
Comparison inhibit timer
Judging timer
Complete
㸦output㸧
Judging
㸦output㸧
㸦Over, go or under㸧
t1t0
t2
t3
Hold
Pause
㸦input㸧
Stable
㸦output㸧
Restart setting SP1 80%
(Final - SP1) * 0.8
Over
Under
No.2
No.1
No.3
No.4
No.5
Paused
㸦output㸧
No.6
No.7
No.8
No.9
No.10
No.11
No.12
No.13
No.14
*1
*2
*3
*4
*5
*6
*7
*8
* With power failure restoration, the operation restarts on start input.
t0: comparison inhibit time 1
t1: comparison inhibit time 2
t2: judging time
t3: complete output time
SP1: set point 1
SP2: set point 2
SP3: set point 3
