8 List of Setting Items
129
List of Setting Items
Chapter
8
Initial value: Factory default value
Per code: Change the setting value per code
NOV.RAM: Setting values are saved in NOV.RAM (non-volatile RAM).
F-RAM: Setting values are saved in F-RAM (non-volatile RAM).
Lock1 (soft): Setting value change is prohibited using Lock1 of the soft switch (setting mode 2-9).
Lock2 (soft): Setting value change is prohibited using Lock2 of the soft switch (setting mod
e 2-9).
LOCK (SW): Setting value change is prohibited using the LOCK switch on the rear panel.
Display only: Settings cannot be changed.
■Setting mode 0
■Setting mode 1
Name
Initial
value
Setting range
Lock1
(soft)
Lock2
(soft)
LOCK
(SW)
Display
only
Communication
command
1 Upper limit 000.00 0 to 99999
◎
W22(R/W)
2 Lower limit 000.00 0 to 99999
◎
W23(R/W)
3 Near zero 000.00 0 to 99999
◎
W24(R/W)
4 Set point 1 000.00 0 to 99999
◎
W10(R/W)
5 Set point 2 000.00 0 to 99999
◎
W11(R/W)
6 Compensation 00.00 0 to 9999
◎
W15(R/W)
7 Over 0.00 0 to 999
◎
W13(R/W)
8 Under 0.00 0 to 999
◎
W14(R/W)
9 Final 000.00 0 to 99999
◎
W12(R/W)
Name
Initial
value
Setting range
Lock1
(soft)
Lock2
(soft)
LOCK
(SW)
Display
only
Communication
command
1 Comparison inhibit time 1 0.50 0.00 to 9.99
◎
W21(R/W)
2 Judging time 1.50 0.00 to 9.99
◎
W20(R/W)
3 Complete output time 3.00 0.00 to 9.99
◎
W28(R/W)
4 Compensation feeding time 1.00 0.00 to 9.99
◎
W17(R/W)
5 Number of times for AZ 01 00 to 99
◎
W26(R/W)
6 Number of times for judging 01 00 to 99
◎
W27(R/W)
7
Auto free fall compensation
regulation value
98.00 00000 to 99999
◎
W16(R/W)
8 Comparison inhibit time 2 0.50 0.
00 to 9.99
◎
W29(R/W)
9 Tare setting 000.00 00000 to 99999
◎
W25(R/W)
8 List of Setting Items
