130
8 List of Setting Items
130
List of Setting Items
Chapter
8
■Setting mode 2
Name
Initial
value
Setting range
Lock1
(soft)
Lock2
(soft)
LOCK
(SW)
Display
only
Communication
command
1 Weighing function 1 0000 0000 to 2224
◎
W31(R/W)
Discharging control mode 0
2: External selection
1: Discharge control
0: Feeding control
Final and over/under
comparison
0
2: Comparison OFF
1: Net weight
0: Gross weight
Upper/lower limit
comparison
0
2: Comparison OFF
1: Net weight
0: Gross weight
Near zero comparison mode 0
4: Comparison OFF
3: |Net weight|
2: |Gross weight|
1: Net weight
0: Gross wei
ght
2 Weighing function 2 00000 00000 to 21312
◎
W32(R/W)
Output selection (21 pin) 0
2:
Weight error and seq. error
1: Seq. error
0: Weight error
Output selection (22 pin) 0
1: Complete output
0: Go output
Over/under comparison
mode
0
3: Compare when complete
output is ON and hold the
weight value
2: Compare when complete
output is ON
1: Compare when external
judging input is ON
0: Compare regularly
Complete signal ou
tput
mode
0
2: Turns ON only for the
complete output time
either after the SP3
signal has turned ON and
the judging timer has
elapsed or from when the
weight value has become
stable
1: Turns ON only for the
complete output time
from when the weight
value has become stable
after the judging timer
has elapsed
0: Compare regularly
Upper/lower limit
comparison mode
0
1: Compare when external
judging input is
ON
0: Compare regularly
3 Weighing function 3 0141 0010 to 3191
◎
W33(R/W)
Auto free fall compensation
coefficient
0
3: 1/4
2: 2/4
1: 3/4
0: 1
Auto free fall compensation 1
2: ON
(communication option OFF)
1: ON
0: OFF
Average number of times for
auto free fall compensation
4 1 to 9
Preset tare weight 1
1: ON
0: OFF
To Next Page
