29
4 Performing Final Discharge Control
29
Performing Final Discharge
Chapter
4
4-3. Setting procedures
4-4. Discharging Control Mode
Perform the feeding/discharging control
settings. The "external selection" can switch
between feeding/discharging via signals from
external I/O connector.
When set to external selection, set one of the
input selections 1 to 6 (A8 and pins B1 to B5) to "feeding/discharging" to switch between feeding/
discharging.
Feeding control applies when OFF (H
I), and discharging control applies when ON (LO).
(Refer to P.37 "4-9.External I/O signal (control connector)" for settings for input selections 1 to 6.)
4-5. Selecting a control procedure
Set sequence mode and simple comparison
mode.
When set to "sequence mode (with power
failure restoration)", operation will restart
based on the restart setting (P.48 "5-3.Sequence
control (with adjust feeding)"P.50 "5-
4.
Sequence control (with external judging)"P.52
"5-5.Sequence control (with pause input/power failure restoration) [CASE 1]") in the event of a power
outage.
Selecting a discharge procedure
Select the feeding/discharging control.
Select simple comparison/sequence mode.
Select the net and gross weight.
Make selections for weighing comparison and judging.
Set to correct for fluctuation of compensation.
Set additional functions to perform weighing more accurately.
(Setting mode 2-1, 2-2)
(Setting mode 2-3)
(Setting mode 2-1)
(Setting mode 2-4)
Selecting a control procedure
Comparison setting
Judgment settings
Auto free fall compensation
Sequence control settings
[Weighing function 1] (Setting mode 2-1)
2: External selection
1: Discharging control
0: Feeding control
Discharging control mode
[Sequence mode] (Setting mode 2-4)
2: Sequence mode
(with power failure restoration)
1: Sequence mode
(with power failure restoration)
0: Simple comparison mode
Weighing mode
To Next Page
