4 Performing Final Discharge Control
42
Performing Final Discharge
Chapter
4
4-9-5.External output signal
Signal Explanation
Set point 1,
set point 2,
set point 3
● In simple comparison mode
Conditions under which each signal turns ON are as follows:
-SP1 output: Weight value ≧ final setting value - set point 1 setting value
- SP2 output: Weight value ≧ final setting value - set point 2 setting value
- SP3 output: Weight value ≧ final setting value - compensation setting value
(Select the value in accordance with fina
l and over/under comparison weight)
● In sequence mode
When weighing start signal is ON, weighing sequence starts and each signal turns
ON. Conditions under which each signal turns OFF are as follows:
- SP1 output: Weight value ≧ final setting value - set point 1 setting value
- SP2 output: Weight value ≧ final setting value - set point 2 setting value
- SP3 output: Weight value ≧ final setting value - com
pensation setting value
(Select the value in accordance with final and over/under comparison weight)
Complete
● In simple comparison mode
Select output mode in complete signal output mode.
The timing with which output turns ON depends on complete output time.
● In sequence mode
[When judging is ON]
Select output mode in complete signal output mode.
The timing with which output turns ON depends on complete
output time.
[When judging is OFF]
Complete output turns ON in the event of OFF edge of SP3 signal, ignoring setting
of complete signal output mode. The timing with which output turns ON depends on
complete output time.
Near Zero
Output turns ON when weight value (selected in near zero comparison mode) ≦
near zero setting value with comparison set to compare regularly only.
Stable
Output turns ON when the
weight value is stable.
(Refer to P.24 "3-5-7.Motion detection (MD) (Setting mode 2-7, 4-7)" for details.)
Over, under, go
● In simple comparison mode
Select comparison timing in over/under comparison mode.
● In sequence mode
Hold weight value, ignoring setting of over/under comparison mode and comparing
when complete output is ON. (Only when judging is ON.)
Conditions for which each signal turns ON
- Unde
r: weight value ＜ final setting value - under setting value
- Over: weight value ＞ final setting value + over setting value
(Select the value in accordance with final and over/under comparison weight)
- Final: final setting value + over setting value ≧ weight value
≧ final setting value - under setting value
Upper limit, lower limit
Select comparison regularly or comparison is made when the external ju
dging
input is ON for upper/lower limit comparison mode.
Conditional equation: Lower limit output turns ON when weight value < lower limit
setting value.
Upper limit output turns ON when weight value > upper limit setting value.
(Select the value in accordance with upper/lower limit comparison weight)
