41
4 Performing Final Discharge Control
41
Performing Final Discharge
Chapter
4
JUDGE
<Level input, edge input>
Comparison judge is performed while this is turned ON during simple
comparison control. This input terminal becomes HOLD in accordance with
setting.
This signal cannot be used as JUDGE unless over/under comparison mode
or upper/lower limit comparison mode is set as "comparison is made when
the judging input is ON".
Furthermore, if over/under comparison mode is s
et to "comparison is made
when external judging input is ON" during sequence mode, weighing is
completed with over/under comparison at ON edge after operation of
complete signal output mode.
Pause <Edge input>
This signal is enabled when sequence mode is set to "restoration ON".
Weighing is paused at ON edge.
Total print <Edge input>
Prints and clears the accumulated data at ON edge. However, an RS-232
C
interface (optional) and printer must be connected or the total will not be
printed.
Delete print <Edge input>
This signal deletes the last printed data at ON edge. However, an RS-232C
interface (optional) and printer must be connected or delete print will not be
performed.
Signal Explanation
To Next Page
