5 Timing Chart for Weighing
51
Timing Chart for Weighing
Chapter
5
No. Sequence control operation
Checking status
display
Keys for relevant settings
External input signal
to be used
External output
signal to be used
1 Waiting for start signal input
SP1/SP2/SP3 blinks
SP1/SP2/SP3 blinks at medium speed
2 Execution of tare subtraction Tare lights up
Setting mode 2-1:
final and over/under comparison
Tare subtraction
(5 pin)
Sets the compared weight value to z
ero (In the chart, tare subtraction is executed by external input and the NET weight is set to zero.)
3 Start signal ON is input
SP1/SP2/SP3
lights up
Setting mode 5-1: input selection Start (input selection)
Set point 1 (7 pin) ON
Set point 2 (8 pin) ON
Set point 3 (9 pin) ON
4
Final - set point 1 net weight
SP1 light goes out
Setting mode 0-4: set point 1
Setting mode 0-9: final
Setting mode 2-1:
final and
over/under comparison
Set point 1 (7 pin)
OFF
* 1
Set point 1 output is OFF when compared weight value final setting value - set point 1 setting value
5
Operation of the comparison
inhibit timer
Setting mode 1-1:
comparison inhibit time (t0)
6
Final - set point 2 net weight
value
SP2 light goes out
Setting mode 0-5: set point 2
Setting mode 0-9: final
Setting mode 2-1:
final and over/under comparison
Set p
oint 2 (8 pin)
OFF
* 2
Set point 2 output is OFF when compared weight value final setting value - set point 2 setting value
7
Operation of the comparison
inhibit timer
Setting mode 1-8:
comparison inhibit time (t1)
8
Final - compensation net
weight
SP3 light goes out
Setting mode 0-6: compensation
Setting mode 0-9: final
Setting mode 2-1:
final and over/under comparison
.
Set point 3 (9 pin)
OFF
* 3
Set poin
t 3 output is OFF when compared weight value final setting value - compensation setting value
9 Operation of the judging timer Setting mode 1-2: judging time (t2)
10
Waiting for judging signal input
Output of adjust feeding in prog-
ress signal
HI or LO blinks
Setting mode 0-7: over
Setting mode 0-8: under
Setting mode 0-9: final
Setting mode 2-1:
final and over/under comparison
Setting mode 2-2:
over/under
comparison mode
Setting mode 5-2: output selection
Output selection:
waiting for external
judging (23 pin) ON
* 4
External judging input is enabled when setting mode 2-2: over/under comparison mode is set to 1: compare when external judging input is ON.
If the over-under comparison result is anything other than GO, the displayed result will blink and a waiting for external judging signal will turn
ON (
signal for over/under comparison result will also turn ON)
Switches to [No.12] sequence if over/under comparison result is GO.
* 6
Judged to be under when compared weight value final setting value under setting value
Judged to be over when compared weight value final setting value over setting value
Judged to be GO when final setting value over setting value compared weight value final se
tting value under setting value
11
Waiting for input of judging signal
Output of adjust feeding in prog-
ress signal
HI or LO light goes
out
Setting mode 0-7: over
Setting mode 0-8: under
Setting mode 0-9: final
Setting mode 2-1:
final and over/under comparison
Setting mode 1-2: judging time (t2)
Setting mode 5-1: input selection
Setting mode 5-2: output selection
Judging (input selec-
tion)
Output selection:
waiting for external
judging (23 pin) OFF
* 5
When judging signal ON is input, the blinking judging result will go out, output of waiting for external judging will turn OFF, and judging timer
will begin operating.
Switches to [No.10] sequence if the over/under comparison result is anything other than GO when judging is re-executed after the judging
timer has elapsed.
Switches to [No.12] sequence if ov
er/under comparison result is GO.
* 6
Judged to be under when compared weight value final setting value under setting value
Judged to be over when compared weight value final setting value over setting value
Judged to be GO when final setting value over setting value compared weight value final setting value under setting value
12
Output of complete signal and
output of judging signal
HOL
D lights up
GO lights up
Setting mode 1-3: complete output time (t3)
Setting mode 2-2: output selection (22 pin)
Setting mode 2-2:
complete signal output mode
Output selection: GO
(22 pin) ON
Output selection:
complete (22 pin) ON
* 7
The timing of complete signal output depends on setting mode 2-2: complete signal output mode (shown in the chart as 1: after judging
timer has elapsed.)
The timing of over/u
nder comparison holds the weight value compared at complete ON regardless of setting mode 2-2:over/under compar-
ison mode
13
After complete output timer has
elapsed
HOLD light goes
out
GO light goes out
Setting mode 1-3:
complete output time (t3)
Setting mode 2-2: output selection (22 pin)
Output selection: GO
(22 pin) OFF
Output selection:
complete (22 pin) OFF
14
Waiting for input of start signal
for next
weighing
SP1/SP2/SP3
blinks
SP1/SP2/SP3 blinks at medium speed
......
