110
6 Useful Functions
110
Useful Functions
Chapter
6
○ Command bit
- Gross weight/net weight display switch Changes gross weight display to net weight display at ON
edge.
Changes gross weight display to gross weight at OFF edge.
- One-touch tare subtraction Performs tare subtraction at ON edge.
- One-touch tare subtraction reset Resets tare subtraction at ON edge.
- Digital zero Turns the gross weight to zero at ON edge.
- Digital zero reset Resets digi
tal zero at ON edge.
- Hold *1 Holds the current weight value at ON edge.
Releases hold at OFF edge.
- Accumulation clear Clears the accumulation data at ON edge.
- Accumulation command Accumulates the current weight value at ON edge.
- Start Starts weighing at ON edge.
- Stop Stops weighing and turns the stop signal to ON level at ON
edge. Turns the stop signal to OFF level at OFF edge.
- Pause Pauses weighing
at ON edge.
- Judging input Rejudges the result at ON edge. Please note that rejudging is
performed when the over/under comparison mode is set to
"external judging input" in sequence mode.
- Zero calibration Performs zero calibration at ON edge.
- Span calibration (actual load) Performs span calibration (actual load calibration) at ON
edge.
- Span calibration (equivalent input) Performs span calibration (eq
uivalent calibration) at ON
edge.
- R/W (R:1/W:0) Specifies READ/WRITE of command.
READ: Turn ON when reading setting values for F701+.
WRITE: Turn OFF when writing setting values for F701+.
- Command request Give ON edge when performing read or write command.
- Survival verification request Change this bit to check whether F701+ is operating
normally. F701+ reverses this bit status in order to output a
resp
onse to a survival verification request.
To Next Page
