Unipulse F701+ User Manual

111
6 Useful Functions
111
Useful Functions
Chapter
6
■ IN data (13 words)
1st word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
F701+ → PLC
Gross weight
(bit)
DWORD mode
Mode 0 Mode 1
(HI) (LO)
2nd word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Gross weight
(bit)
(LO) (HI)
(1) Sequence error (0 to 9) (2) Calibration error (0 to 9)
(3) Calibration process status (4) ZALM
(5) +LOAD (6) -LOAD
(7) OFL2
3rd word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Net weight
(bit)
(HI) (LO)
4th word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Net weight
(bit)
(LO) (HI)
7th word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Status 1
(bit)
(5)(6)(7) (4)(3) (2) (1)
(1) HI LIM (2) LO LIM
(3) HI (4) GO
(5) LO (6) SP1
(7) SP2 (8) SP3
(9) NZ (10) COMPL.
8th word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
(bit)
Status 2
(10) (9)(8) (5)(6)(7) (4)(3)(2) (1)
(1) Decimal place (0;None, 1:0.0, 2:0.00, 3:0.000)
(2) Unit (0;None, 1:t, 2:g, 3:kg, 4:lb, 5:N)
(3) STAB (4) HOLD
(5) TARE (6) NET
(7) ZT (8) LOCK(SW)
(9) LOCK (settings)
9th word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
(bit)
Status 3
(7)(6)(5) (2)(3)(4)(8) (1)
(9)
(1) Gross weight/net weight display switch response
(2) One-touch tare subtraction response
(3) One-touch tare subtraction reset response (4) Digital zero response
(5) Digital zero reset response (6) Hold response
(7) Accumulation clear response (8) Accumulation command response
(9) Start response (10) Stop response
(11) Pause response (12) Judging input response
10th word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
(bit)
Command response
(10) (9)(8) (5)(6)(7) (4)(3)(2) (1) (11)(12)
