5 Timing Chart for Weighing
49
Timing Chart for Weighing
Chapter
5
↓
↓
↓
↓
↓
↓
↓
↓
↓
↓
↓
↓
↓
No. Sequence control operation
Checking status
display
Keys for relevant settings
External input signal
to be used
External output
signal to be used
1 Waiting for start signal input SP1/SP2/SP3 blinks
SP1/SP2/SP3 blinks at medium speed
2 Execution of tare subtraction Tare lights up
Setting mode 2-1:
final and over/under comparison
Tare subtraction (5
pin)
Sets the compared weight value to ze
ro (In the chart, tare subtraction is executed by external input and the NET weight is set to zero.)
3 Start signal ON is input
SP1/SP2/SP3
lights up
Setting mode 5-1: input selection Start (input selection)
Set point 1 (7 pin) ON
Set point 2 (8 pin) ON
Set point 3 (9 pin) ON
4
Final - set point 1 ≦ net weight
SP1 light goes out
Setting mode 0-4: set point 1
Setting mode 0-9: final
Setting mode 2-1:
final and o
ver/under comparison
Set point 1 (7 pin)
OFF
* 1
Set point 1 output is OFF when compared weight value ≧ final setting value - set point 1 setting value
5
Operation of the comparison
inhibit timer
Setting mode 1-1:
comparison inhibit time (t0)
6
Final - set point 2 ≦ net weight
value
SP2 light goes out
Setting mode 0-5: set point 2
Setting mode 0-9: final
Setting mode 2-1:
final and over/under comparison
Set po
int 2 (8 pin)
OFF
* 2
Set point 2 output is OFF when compared weight value ≧ final setting value - set point 2 setting value
7
Operation of the comparison
inhibit timer
Setting mode 1-8:
comparison inhibit time (t1)
8
Final - compensation ≦ net
weight
SP3 light goes out
Setting mode 0-6: compensation
Setting mode 0-9: final
Setting mode 2-1:
final and over/under comparison
Set point 3 (9 pin)
OFF
* 3
Set point
3 output is OFF when compared weight value ≧ final setting value - compensation setting value
9
Operation of the judging timer
Adjust feeding judging
Setting mode 0-8: under
Setting mode 0-9: final
Setting mode 1-2: judging time (t2)
Setting mode 2-1:
final and over/under comparison
Setting mode 2-4: adjust feeding
* 4
Executes adjust feeding judging if adjust feeding selection in setting mode 2-4: sequence
mode is 1: Adjust feeding ON
- Judged to be under and switches to [No.10] sequence when compared weight ＜ final setting value － under setting value
- Switches to [No.12] sequence when compared weight ≧ final setting value － under setting value
10 Operation of the adjust feeding timer SP3 lights up Setting mode 1-4: adjust feeding time Set point 3 (9 pin) ON
* 5 While the adjust feeding timer is running,
set point 3 signal is ON
11
Operation of the judging timer
Adjust feeding judging
Setting mode 0-8: under
Setting mode 0-9: final
Setting mode 1-2: judging time (t2)
Setting mode 2-1:
final and over/under comparison
Setting mode 2-4: adjust feeding
* 4
Executes adjust feeding judging if adjust feeding selection in setting mode 2-4: sequence mode is 1: Adjust feeding ON
- Judged to be under and switches to
[No.10] sequence when compared weight < final setting value - under setting value
- Switches to [No.12] sequence when compared weight ≧ final setting value － under setting value
12
Output of complete signal and
output of judging signal
HOLD lights up
HI or GO lights up
Setting mode 0-7: over
Setting mode 0-9: final
Setting mode 1-3:
complete output time (t3)
Setting mode 2-1:
final and over/under compari
son
Setting mode 1-3:
complete output time (t3)
Setting mode 2-2:
output selection (22 pin)
Setting mode 2-2:
complete signal output mode
Over (10 pin) ON
Output selection: GO
(22 pin) ON
Output selection:
complete (22 pin) ON
* 4
Over is ON when compared weight value ＞ final setting value + over setting value
GO is ON when final setting value + over setting value ≧ compared weight value ≧ final setting va
lue - under setting value
* 6
The timing of complete signal output depends on setting mode 2-2: complete signal output mode (shown in the chart as 1: after judging
timer has elapsed)
The timing of over/under comparison holds the weight value compared at complete ON regardless of setting mode 2-2:over/under compar-
ison mode
13
After complete output timer has
elapsed
HOLD light goes
out
HI or GO light goes
out
Setting mode 1-3:
complete output time (t3)
Setting mode 2-2:
output selection (22 pin)
Over (10 pin) OFF
Output selection: GO
(22 pin) OFF
Output selection:
complete (22 pin) OFF
......
