Unipulse F701+ User Manual

82
6 Useful Functions
82
Useful Functions
Chapter
6
15 (0x0F) Write Multiple Coils
For slave coils, data for a specified number of coils starting from a specified address is changed.
When broadcast (0) is specified, coils of all slave devices with the same address will be rewritten.
The coil address, new number of bytes and output value are specified in the request.
* If rewriting a coil which turns the signal to ON level or OFF level, be sure
to set the priority of the
level input signal (setting mode 4-7) to "1: communication priority".
* N = Number of coils/8, N = N+1 in case the division is not possible.
Example) Turning ON/OFF accumulation clear (address 00009) starting
from digital zero (address 00005).
Note that the relative address is 0x04 when writing in digital zero.
The example shows how ON (1) and OFF (0) of the F701+ is rewritte
n.
Unused bits are filled in with 0.
* Consider execution confirmation of the coil to be something that is completed by a normal
response.
* Do not execute commands in the address combinations listed below.
When executed, commands will be carried out one by one, but may not operate properly.
- Addresses 00001 and 00002 - Addresses 00009 and 00010
- Addresses 00003 to 00006 - Addresses 00011 to 00013
- Address
es 00007 and 00008
[Request]
Function 1 byte 0x0F
Start address 2 bytes 0x0000 to 0xFFFF
Number of coils 2 bytes 0x0001 to 0x07B0
Number of bytes 1 byte N *
Changed data N x 2 bytes
[Response]
Function 1 byte 0x0F
Start address 2 bytes 0x0000 to 0xFFFF
Number of coils 2 bytes 0x0001 to 0x07B0
[Error response]
Error code 1 byte 0x8F (Function +0x80)
Exception code 1 byte 01 or 02 or 03
[Request]
Function 0F
[Response]
Function 0F
Start
address (HI) 00 Start address (HI) 00
Start address (LO) 04 Start address (LO) 04
Number of coils (HI) 00 Number of coils (HI) 00
Number of coils (LO) 05 Number of coils (LO) 05
Data bytes 01
(Digital zero to accumulation clear) 10
Coil 00012 00011 00010 Accumulation
clear
Hold
Off
Hold
On
Digital
zero
reset
Digital
zero
Bit 0 0 0 1 0 0 0 0
0x10
