87
6 Useful Functions
87
Useful Functions
Chapter
6
17 (0x11) Report Slave ID
The slave device returns the current status and the operation mode.
The content of the response will vary according to the product.
* The slave ID is different from the Address.
Example) Reading the slave ID.
* Version information is represented in 3 bytes.
Version is 1.23 in the case of 0x01, 0x02 and 0x03.
08 (0x08) Diagnostic code (Diagnostics)
The communication status between the master and slaves can be checked by requesting a diagnosis.
Content of check differs depending on the sub-functions added after the general functions.
The slave device responds by returning the received request frame except when there is an error.
Also, all counters for diagnosis are cleared when the power is turned ON.
[Request]
Function 1 byte 0x11
[Response]
Function 1 byte 0x11
Number of byt
es 1 byte
Slave ID 1 byte
RUN Indicator 1 byte
0x00:
Weight error or calibration error
0xFF: Normal
Additional
information
3 byte Version
[Error response]
Error code 1 byte 0x91 (Function +0x80)
Exception code 1 byte 01
[Request]
Function 11
[Response]
Function 11
Number of bytes 5
Slave ID
RUN Indicator 00
Additional information *
[Request]
Function 1 byte 0x08
Sub-function 2 bytes
Data N x 2 bytes
[Response]
Function 1 byte 0x08
Sub-func
tion 2 bytes
Data N x 2 bytes
[Error response]
Error code 1 byte 0x88 (Function +0x80)
Exception code 1 byte 01 or 03
