13.17 Run Tab
of the field. This will cause an on-screen keyboard to pop up where the user can
enter the file name directly on the screen.
Open button Clicking on the Open button, will open the currently selected file
and return to the previous screen.
Cancel button Clicking on the Cancel button will abort the current loading pro-
cess and cause the screen to switch to the previous image.
Action buttons A series of buttons gives the user the ability to perform some of
the actions that normally would be accessible by right-clicking on a file name in a
conventional file dialog. Added to this is the ability to move up in the directory
structure and directly to the program folder.
• Parent: Move up in the directory structure. The button will not be enabled in
two cases: when the current directory is the top directory or if the screen is in
the limited mode and the current directory is the program folder.
• Go to program folder: Go home
• Actions: Actions such as create directory, delete file etc.
13.17 Run Tab
This tab provides a very simple way of operating the robot arm and control box,
with as few buttons and options as possible. This can be usefully combined with
password protecting the programming part of PolyScope (see 15.3), to make the
robot into a tool that can run exclusively pre-written programs.
Version 3.4.5
Copyright © 2009–2017 by Universal Robots A/S. All rights reserved.
II-63 CB3
