VHF E5 - Scope of Delivery Check

5.1 Checking the scope of delivery
Unpack the machine and ensure that you have
received the following items:
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
17 18 19
1. 1x Machine E5
2. 1x Ethernet network cable
3. 1x Power cable
4. 1x Torque screwdriver 1.5Nm with bitTX20
5. 2x Angle screwdriver
n
1x TX10
n
1x TX25
6. 1x 5.5mm wrench to remove a broken tool
7. 1x Administrated Tool Board for tool storage
8. 1x Spindle service set
9. 1x Calibration set:
n
1x Micrometer
n
3x Calibration blank
n
1 x AirTool P250-F1-40-T
10. 1x Cleaning brush for the blank holder
11. 1x Microfiber cloth
12. 1x Drill bit for tool positions (2.8 mm)
13. 2x Spare screw for the blank holder
14. 4x Cover cap for fixing screws of the A-B axis module
15. 6x Cover cap for blank holder
For customer service
16. 1x Insert for the AirTool
17. 1x Tool magazine insert
18. Fasteners for the top and bottom service covers
n
4x Fixing bar
n
4x Clamping block
[[[Undefined variable GLB_DEN-phrases-
SL1.NotDepicted]]]
n
1x Supplement for unpacking and installing the
machine
n
Transport lock
3x Foam insert
2x Accessory box
1x Spindle lock
n
Packing set
1x Transport carton including floor insert
1x Upper and lower padding
3x Working chamber door stopper
1x Transport protection cover
1x Housing protection cover
Original Operating Instructions:E5
Version: 4/27/2023
Installation
