VHF E5 - Technical Specifications

4.9 Technical data
Dimensions (W/D/H)
Unit Value
Footprint (approx.) mm
in
387 x 370
15.2x 14.6
Housing fully closed
(approx.)
mm
in
472x 484x734
18.6x 19.1x28.9
Minimum required space for
operation (approx.)
mm
in
680x 760x780
26.8x 25.2x30.7
Base system
Unit Value
Weight (approx.) kg
lbs
43
95
Axes
– Rotational axis A
5
360°/ ± 35°
Overvoltage category
(IEC60664-1)
II
External air extraction system
Unit Value
Minimum extraction capacity l/min
cfm
2,500 (at 220 hPa)
88.3 (at 3.2 psi)
Suction unit Designed for the commercial
use in the dental sector
Equipped with a filter of the
filter class M
Ambient conditions
Unit Value
Relative air moisture 80%, non-condensing
Ambient temperature for stor-
age/transport
°C
°F
-20 – 60
-4 – 140
Ambient temperature for
operation
°C
°F
10 – 35
50 – 95
Location type Indoor
Maximum height above
mean sea level
m
ft
2000
6561
Ambient air (IEC60664-1) Dust free, pollution degree 2
Spindle
Unit Value
Model SFE 300E (synchronous)
Maximum rotational speed rpm 60,000
Nominal power under
continuous operation (S1)
W 300
Nominal power under unin-
terrupted periodic operation
(S6)
W 400
Peak power (P
max
) W 800
Diameter collet chuck mm 3
Tool changer
Unit Value
Maximum tools in magazine 17
Maximum tool length mm 40
Standard blank holder
Unit Value
Min./ max. disc diameter mm 98.5/ 98.8
Maximum disc height mm 40
Min./ max. height of the disc
rim
mm 9.8/ 10.5
Maximum block dimensions
(L/D/H)
mm 40x 20x 20 (requires block
holder)
Sound emission
Operating condition Unit Value
Processing dB(A) 82.98
All other operating condi-
tions
dB(A) <70
Measuring conditions Value
Machined material Composite (VITA CAD temp block)
Condition of the tools worn
Measured value Sound pressure level (distance:1m)
Measurement according to ISO 3746, survey method 3
Connections
Unit Value
Power connection
(and maximum power
consumption in watts)
VAC
Hz
W
100 – 240
50/60
500
Glass fuse T6,3A L250V
Network port
– Speed
RJ-45
10BASE/100BASE-
TX/1000BASE-T (Auto-
sensing)
USB port 2x 2.0 A
1x 2.0 B
Data port for supported
suction unit or switching unit
Yes
Get to know your machine
EN 13
Original Operating Instructions: E5
Version: 4/27/2023
