VHF E5 - Working Chamber Door Gasket Exchange

7.20 Exchanging the gasket of the
w orking chamber door
The gasket of the working chamber door is clamped to
the edge of the machine housing which surrounds the
opening to the working chamber.
FIG. 234 GASKET OF THE WORKING CHAMBER DOOR (MARKED ORANGE)
1. Have ready:
n
1x Spare gasket
FIG. 235
n
1x Cleaning cloth
FIG. 236
2. Open the working chamber door.
3. Remove the existing door gasket. For this, use the
gap at the top of the door gasket.
4. Clean the surface on which the gasket is located
with the cloth.
FIG. 237
FIG. 238
FIG. 239
Maintenance
EN 85
Original Operating Instructions: E5
Version: 4/27/2023
