VHF E5 - Main Fuse Exchange

7.24 Exchanging the main fuse
The internal power supply of the machine has a main
fuse that is accessible from the outside and can be
exchanged if necessary.
As a replacement fuse, only use a fuse of the fol-
lowing type: T6,3A L250V
A new main fuse is available as spare part from
customer service.
1. ⚠ DANGER! Switch off the machine at the main
power switch.
2. Remove the power cord from the connection
panel.
3. Remove the cover of the fuse.
FIG. 280 COVER OF THE FUSE (MARKED ORANGE)
4. Remove the defective fuse and replace it with a
new fuse.
5. If you do not have a replacement fuse ready, take
the replacement fuse from the right side of the fuse
cover and put it into the left side of the fuse cover.
6. Remount the fuse cover.
