The installation of the suction hose with the
optional hose connection is complete.
FIG. 17 INSERTING THE HOSE CONNECTION INTO THE OPENING FOR THE AIR
EXTRACTION SYSTEM
5.2.4 Establishing the electric connection
The machine requires an uninterruptible power supply
for proper operation.
1. Plug the provided power cable into the power con-
nection at the connection panel of the machine.
2. NOTICE! To avoid job interruptions, install an unin-
terruptible power supply (UPS), type online / VFI
(IEC62040-3, Class 1) if there are regular power fail-
ures or frequent mains voltage fluctuations.
3. Insert the plug of the cable into a socket that is pro-
tected by a Residual Current Device/ Ground Fault
Circuit Interrupter.
FIG. 18
Original Operating Instructions:E5
Version: 4/27/2023
Installation
EN 20
