1 2 Part
Replacement inter-
val or conditions
Description
X
Fixing latches and clamping
blocks for upper and lower
service covers
If defective
 Exchanging the fuser latches and
clamping blocks on the upper service
cover – on page81
 Exchanging the fuser latches and
clamping blocks on the lower service
cover – on page83
X
Gasket of the working
chamber door
If defective  Exchanging the gasket of the
working chamber door – on page85
X
Holder for AirTool insert If defective  Exchanging tool magazine inserts
and associated holders – on page54
X
Holder for tool magazine
insert
If defective  Exchanging tool magazine inserts
and associated holders – on page54
X
Locking bolt for system
module
If defective  Exchanging the system module
locking bolt – on page76
X
Main fuse T6,3A L250V If defective  Exchanging the main fuse – on
page94
X
Measuring key If defective  Exchanging the measuring key –
on page79
X
Measuring key protective cap If defective  Exchanging the measuring key
protective cap – on page78
X
Power cable If defective
See
 Establishing the electric connection
– on page20
X
Service cover, bottom If defective See
 Exchanging the system module –
on page73
X
System module If defective  Exchanging the system module –
on page73
X
Top service cover If defective See
 Exchanging the spindle unit – on
page66
X
Transport package If defective
X
Transport securing set If defective
*
These are recommendation guidelines. Depending on the processing material and how well the machine is cleaned, these values may
differ.
