VHF E5 - Page 80

11. Handle the spare measuring key.
12. Plug the measuring key cable connector into the
socket in the A-B axis module.
13. Insert the spare measuring key into the opening as
shown.
14. Use the TX10 angle screwdriver to tighten the
spare measuring key with the 2 screws.
FIG. 215
FIG. 216
FIG. 217
15. Close the working chamber door.
16. Start DENTALCNC.
17. Switch on the machine at the main power switch.
Original Operating Instructions:E5
Version: 4/27/2023
Maintenance
EN 80
