Rev AB Integral Parts and Accessories 3-5
Videojet 8520 Operator Manual
Optical Fibre
The optical fibre is fitted between the product sensor and controller.
Accessories
Protective Caps for Cartridges
The protective caps protect the nozzle plate from mechanical damage and
from drying out in storage.
Mounting System for Single Head mounting
The mounting system allows fast and simple printhead mounting.
Figure 3-7: Optical Fibre
Figure 3-8: Protective Caps for Cartridges
Figure 3-9: Mounting System for Single Head Mounting
