3-6 Integral Parts and Accessories Rev AB
Videojet 8520 Operator Manual
Adjusting Unit for Multi-head mounting
The adjusting unit for multi-head mounting is suitable for all printhead
versions. The adjusting unit allows the printheads to be finely adjusted for
perfect print images.
Adapter Plate and Spacer Plate
The adapter plate and the spacer plate are required if the locating wheel is
used, for mounting the sensor to the printhead.
Figure 3-10: Adjusting Unit for Multi-head Mounting
Figure 3-11: Adapter Plate (left-hand) and Spacer Plate
