Rev AB Installation of the Mounting System (Optional) 3-27
Videojet 8520 Operator Manual
The stainless steel mounting system for red and green printheads is shown
in Figure 3-42. This mounting system is especially well suited for the
pharmaceutical, medical and food industries. The mounting adapter for a
red or green printhead assembly is available in a length of 200 mm.
The stainless steel mounting adapter for blue printhead is shown in
Figure 3-43. The mounting adapter for a blue printhead assembly is
available in a length of 200 mm.
The mounting adapter for a gold printhead assembly is available in a
length of 200 mm.
Figure 3-42: Stainless Steel Mounting System
Figure 3-43: Stainless Steel Mounting Adapter - Blue Printhead
Figure 3-44: Stainless Steel Mounting Adapter - Gold Printhead
