VAST Server and Client Components
There are four components in VAST: one server component--VAST Server, three client
components--VAST LiveClient, VAST Playback, and VAST Matrix.
VAST Server provides a centralized management site for video recording. VAST LiveClient
is a client program for the user to login and modify the server's conguration, edit the server's
recording storage, schedules and many other functions on the server; VAST Playback is
another client program for the user to log in and browse the recorded video database and video
clips related to specic events on the server.
Usage Scenario
The powerful management scalability of VAST makes it suitable for managing small- to large-
scale structures.
All the functions can be simultaneously performed on one single site.
For users who manage large-scale surveillance deployments, please plan the hierarchical
structure rst. Then you can start to add cameras to each station and connect these sub-stations
to the root station. The whole hierarchical management system is thus constructed.
Unlimited No. of Network Cameras , Video Servers...
Router
VAST LiveClient
VAST Server
Network Cameras
VAST Playback
Stand-alone site
Remote Server Structure
Local Server Structure
Router
Login
Login
VAST LiveClient
VAST Playback
Client
(Root station)
VAST CMS Server
VAST Server
(Sub-stations)
NVR
Web Console
Unlimited No. of Network Cameras , Video Servers...
Router
VAST LiveClient
VAST Server
Network Cameras
VAST Playback
Stand-alone site
Remote Server Structure
Local Server Structure
Router
Login
Login
VAST LiveClient
VAST Playback
Client
(Root station)
VAST CMS Server
VAST Server
(Sub-stations)
NVR
Web Console
Please refer to page 231 for
Logical Tree conguration, which
allows for a flexible and use-
oriented privilege control.
