Maintenance
Check pin lock
●●
Check line fixtures
●●
Check indicator lights for correct function
●●
Couplings, dirt pile-up on hydraulic system dust caps
●●
Check insulating mats in engine compartment for damage/condition
●●
Check labels and Operator’s Manual for completeness and condition
●●
Lights and acoustic warning system
11
●●
Check lubricant on live ring
12
●● ●
Check gearing of swivel unit pinion ●●
Lubrication service ( ):
Lubricate the following assemblies/components – see Maintenance label on page 3-5:
• Stabilizer blade
●●
• Swiveling console ●●
• Swiveling cylinder ●●
• Boom ●●
•Stick ●●
• Attachments ●●
• Teeth of live ring ●●
• Live ring (ball bearing) ●●
• Ball sockets (ISO/SAE changeover option) ●●
Functional check ( ):
Check the function of the following assemblies/components. Rectify if necessary:
• Lights and acoustic warning system
●●
• Check pedal function ●●
3.3 Maintenance plan (overview)
Work description
For servicing and maintenance on the attachment, please refer to the operation and maintenance manual of
the attachment manufacturer.
Maintenance plan/operating hours (o/h)
Maintenance
(once a day)
Every 50 o/h
Every 250 o/h
Every 500 o/h
Every 1000 o/h
once a year
Every 2000 o/h
Customer
Authorized
service center
