WEG SSW-06 User Manual

17
SSW-06 - QUICK PARAMETER REFERENCE
MOTOR PARAMETERS P400 to P499
P400
(1)
Nominal Motor Voltage 0 to 999 380 V 118
P401
(1)
Nominal Motor Current 0 to 2424 20 A 118
P402
(1)
Nominal Motor Speed 400 to 3600 1780 rpm 118
P404
(1)
Nominal Motor Power 0.1 to 2650 75 kW 118
P405
(1)
Motor Power Factor 0 to 1.00 0.89 - 118
P406
(1)
Service Factor 0 to 1.50 1.00 - 119
SPECIAL FUNCTION PARAMETERS P500 to P599
Braking
P500
(1)
Braking Methods 0=Inactive 0=Inactive - 119
1=Reverse Braking
2=Optimal Braking
3=DC-Braking
P501 Braking Time 1 to 299 10 s 122
P502 BrakingVoltageLevel 30to70 30 % 122
P503 Braking End Detection 0=Inactive 0=Inactive - 122
1=Automatic
JOG
P510
(1)
Jog 0=Inactive 0=Inactive - 123
1=Active
P511 JogLevel 10to100 30 % 123
Kick Start
P520
(1)
Kick Start Torque Pulse 0=Inactive 0=Inactive - 124
(according to P202) 1=Active
P521 Kick Start Pulse Time 0.1 to 2 0.1 s 124
P522 KickStartVoltagePulseLevel 70to90 70 % 124
(% Un of the Motor)
P523 KickStartCurrentPulseLevel 300to700 500 % 124
(% In of the Motor)
PROTECTION PARAMETERS P600 to P699
Voltage Protection
P600
(1)
Immediate Undervoltage 0 to 30 20 % 125
(% Un of the Motor)
P601
(1)
Immediate Undervoltage Time 0=Inactive 1 s 125
1 to 99
P602
(1)
Immediate Overvoltage 0 to 30 15 % 125
(% Un of the Motor)
P603
(1)
Immediate Overvoltage Time 0=Inactive 1 s 125
1 to 99
P604
(1)
Voltage Imbalance between Phases 0 to 30 15 % 125
(% Un of the Motor)
P605
(1)
Voltage Imbalance between 0=Inactive 1 s 125
Phases Time 1 to 99
Current Protection
P610
(1)
Immediate Undercurrent 0 to 99 20 % 126
(% In of the Motor)
P611
(1)
Immediate Undercurrent Time 0=Inactive 0=Inactive s 126
1 to 99
P612
(1)
Immediate Overcurrent 0 to 99 20 % 126
(% In of the Motor)
Parameter Description Adjustable Range Factory Unit User´s Pag e
Setting Setting
