WEG SSW-06 User Manual

CHAPTER 3 - INSTALLATION AND CONNECTION
35
Table 3.4 - Power losses for panel fan dimensioning
Model
Power
losses in the
electronics
Fan Power
Total power in the
SCRs at full voltage
Average power
losses 10 starts per
hour 3 x In @ 30s
Total average
power losses 10
starts per hour
3 x In @ 30s
220-575V 575-690V W W W W W
SSW06.0010 - 18 - 0 = By-pass 9 27
SSW06.0016 - 18 - 0 = By-pass 14.4 32.4
SSW06.0023 - 18 - 0 = By-pass 20.7 38.7
SSW06.0030 - 18 - 0 = By-pass 27 45
SSW06.0045 SSW06.0045 33 - 0 = By-pass 40.5 58.5
SSW06.0060 SSW06.0060 33 - 0 = By-pass 54 72
SSW06.0085 SSW06.0085 33 - 0 = By-pass 76.5 109.5
SSW06.0130 SSW06.0130 33 - 0 = By-pass 117 150
SSW06.0170 SSW06.0170 33 - 0 = By-pass 153 186
SSW06.0205 33 - 0 = By-pass 184.5 217.5
- SSW06.0205 33 58
528mA @ 110Vac
264mA @ 220Vac
0 = By-pass 184.5 275.5
SSW06.0255 SSW06.0255 33 58
528mA @ 110Vac
264mA @ 220Vac
0 = By-pass 229.5 320.5
SSW06.0312 SSW06.0312 33 58
528mA @ 110Vac
264mA @ 220Vac
0 = By-pass 280.8 371.8
SSW06.0365 SSW06.0365 33 58
528mA @ 110Vac
264mA @ 220Vac
0 = By-pass 328.5 419.5
SSW06.0412 SSW06.0412 33 58
528mA @ 110Vac
264mA @ 220Vac
0 = By-pass 370.5 461.8
SSW06.0480 SSW06.0480 33 58
528mA @ 110Vac
264mA @ 220Vac
0 = By-pass 432 523
SSW06.0604 SSW06.0604 33 58
528mA @ 110Vac
264mA @ 220Vac
0 = By-pass 543.6 634.6
SSW06.0670 SSW06.0670 33 87
792mA @ 110Vac
396mA @ 220Vac
0 = By-pass 603 723
SSW06.0820 SSW06.0820 33 87
792mA @ 110Vac
396mA @ 220Vac
0 = By-pass 738 858
SSW06.0950 SSW06.0950 33 160
1400mA @ 110Vac
700mA @ 220Vac
3,420 427.5 3,898
SSW06.1100 SSW06.1100 33 210 840mA @ 220Vac 3,960 495 4,533
SSW06.1400 SSW06.1400 33 210 840mA @ 220Vac 5,040 630 5,703
